The XF2U-1415-3A is a 14-pin, 1.27 mm pitch, board-to-board connector manufactured by Omron. It is designed for high-density mounting and provides a reliable electrical connection between two printed circuit boards (PCBs).

Applications

• Industrial equipment
• Medical devices
• Consumer electronics
• Automotive electronics
• Communication systems

Features

• 14 pins
• 1.27 mm pitch
• Board-to-board connection
• High-density mounting
• Reliable electrical connection
• Compact design

Benefits

• Provides secure and stable connection between PCBs
• Suitable for space-constrained applications
• High-density mounting allows for more components on the board
• Reduces the need for wiring harnesses
• Easy to assemble and disassemble
• Durable and long-lasting

Additional Details

The XF2U series connectors are designed to provide a reliable and space-saving solution for board-to-board connections. The 1.27 mm pitch allows for high-density mounting, enabling more components to be placed on the board. The connector is made from high-quality materials to ensure durability and long-term reliability. The gold plating on the contacts provides excellent electrical conductivity and corrosion resistance. The typical operating temperature range is -40°C to +85°C. It is commonly used in applications where space is limited and a reliable connection is required. The connector has a mating height of about 3mm. The mounting style is surface mount.
