The ON Semiconductor 2N5323 is a high-quality NPN bipolar junction transistor (BJT) designed for use in a variety of applications. This versatile component is well-suited for amplification and switching purposes, providing reliable performance in a compact package. The 2N5323 features a robust construction that ensures longevity and stable operation under varying conditions.

Key Features:

• Voltage and Current Ratings: The 2N5323 can handle collector-emitter voltages up to 30V, and collector-base voltages up to 60V. Its collector current rating of up to 1A makes it suitable for moderate power applications.
• Power Dissipation: This transistor is capable of dissipating up to 800mW of power, allowing it to manage a fair amount of heat during operation without the need for excessive cooling measures.
• Gain Bandwidth Product (fT): With a transition frequency of approximately 100MHz, the 2N5323 is an excellent choice for RF and high-speed switching applications.
• High Current Gain: The device boasts a high DC current gain (hFE) which can range from 40 to 240, providing a significant amplification factor for the input signal.

Applications:

The 2N5323's performance characteristics make it well-suited for a range of applications, including:

• Audio amplifiers and pre-amplifiers
• Signal processing
• Switching regulators
• Driver stages in hi-fi systems
• General-purpose switching and amplification circuits

Quality and Reliability:

ON Semiconductor is a trusted name in the industry, known for producing high-quality components that meet rigorous standards. The 2N5323 is manufactured with attention to detail, ensuring that each unit provides consistent performance and reliability. Whether for commercial, industrial, or educational use, this NPN transistor is an excellent choice for designers and engineers seeking a dependable solution for their electronic circuits.

Package Information:

The 2N5323 comes in a TO-98 package, which is a small and lightweight three-lead package. This makes it easy to incorporate into a wide variety of PCB designs and also simplifies the assembly process.
