The ON Semiconductor 2SC5245 is a high-performance NPN bipolar junction transistor designed for a wide range of applications requiring fast switching and high voltage capabilities. This transistor is particularly well-suited for use in power amplification and switching applications, where reliability and efficiency are paramount.

Key Features

• High Voltage: The 2SC5245 is capable of handling high voltage applications, making it ideal for power supplies and other circuits that experience high voltage conditions.
• Fast Switching Speed: Engineered for rapid switching, this transistor can handle quick transitions, which is essential for high-frequency operations and digital circuits.
• Low Saturation Voltage: The low V<sub>CE(sat) helps in reducing power dissipation and improving overall efficiency, which is crucial for power management applications.
• High Current Capacity: With its ability to manage significant current levels, the 2SC5245 is suitable for driving heavy loads, contributing to its versatility in various electronic designs.

Applications

• Power Supply Circuits
• Power Amplifiers
• Switching Regulators
• Motor Controllers
• Inverters

Technical Specifications

Parameter Value Collector-Emitter Voltage (V<sub>CEO) 230V Collector Base Voltage (V<sub>CBO) 230V Emitter Base Voltage (V<sub>EBO) 5V Collector Current (I<sub>C) 1.5A Power Dissipation (P<sub>D) 25W Operating and Storage Junction Temperature Range -55 to +150°C

The ON Semiconductor 2SC5245 NPN transistor is a robust component that offers reliability and performance for demanding electronic circuits. Its high voltage and current capabilities, combined with fast switching speeds, make it an excellent choice for designers looking to optimize their power management and amplification applications.
