ON Semiconductor's BC856ALT1G PNP Transistor

The BC856ALT1G from ON Semiconductor is a high-quality PNP bipolar junction transistor (BJT) that is part of their broad range of discrete semiconductors. This particular transistor is designed for general-purpose amplification and switching applications. With its robust performance and reliability, it is a preferred choice for a wide array of electronic circuits.

Key Features

• Transistor Polarity: PNP - Suitable for providing amplification in a circuit by sourcing current.
• Collector-Emitter Voltage (VCEO): 65V - This indicates the maximum voltage the transistor can handle between its collector and emitter without breakdown.
• Collector Current (IC): 100mA - The maximum continuous current that can flow through the collector of the transistor.
• Power Dissipation (Pd): 250mW - The amount of power the transistor can dissipate without exceeding its maximum operating temperature.
• DC Current Gain (hFE): 420 - A measure of the amplification capability of the transistor, indicating how much the collector current is amplified relative to the base current.
• Package / Case: SOT-23-3 - A small and versatile surface-mount package that allows for efficient use of PCB space.

Applications

The BC856ALT1G is suited for a variety of applications due to its general-purpose nature. It can be used in:

• Signal amplification circuits
• Switching operations
• Audio amplifiers
• Driver stages in hi-fi amplifiers and television circuits
• Linear amplification and switching

Quality and Environmental Compliance

ON Semiconductor is committed to providing environmentally friendly solutions. The BC856ALT1G is compliant with RoHS (Restriction of Hazardous Substances) directives, ensuring that it is manufactured with a focus on environmental safety and sustainability. Additionally, the product is designed to meet the rigorous standards set by ON Semiconductor for reliability and performance.

In summary, the BC856ALT1G PNP transistor from ON Semiconductor is a versatile and efficient component that offers reliable performance for various electronic applications. Its compact size, combined with its electrical characteristics, makes it a valuable part of any electronic component inventory.
