Product Overview: BZX84C15LT1G - ON Semiconductor

The BZX84C15LT1G is a high-performance Zener diode produced by ON Semiconductor, designed to offer excellent voltage regulation with a nominal Zener voltage of 15V. This small-signal Zener diode is a popular choice for various applications, including voltage stabilization and clipping circuits. Its compact SOT-23 package makes it suitable for high-density circuit board designs, providing designers with a reliable solution for voltage regulation in a minimal footprint.

Key Features

• Nominal Zener Voltage: 15V with a tolerance of ±5% for precise voltage regulation.
• Power Dissipation: The device is capable of dissipating up to 225 mW, ensuring stable performance under typical operating conditions.
• Package Type: Supplied in a small SOT-23 surface-mount package, it is ideal for automated assembly processes and space-constrained applications.
• Operating Temperature Range: This diode operates within a wide temperature range from -55°C to +150°C, making it suitable for various environmental conditions.
• Reverse Leakage Current: Exhibits low leakage current, enhancing the overall efficiency of the circuit in which it is used.

Applications

The BZX84C15LT1G Zener diode is versatile and can be used in numerous electronic applications. Its primary use is to provide a stable reference voltage in power supplies. It is also commonly found in overvoltage protection circuits, voltage regulators, and as a component in logic circuits to generate precise voltage references. Additionally, it can be used for clamping applications to protect sensitive electronics from voltage spikes.

Quality and Reliability

ON Semiconductor is known for its commitment to quality, and the BZX84C15LT1G is no exception. This Zener diode is manufactured to meet stringent industry standards, ensuring high reliability and performance consistency. It is RoHS compliant, minimizing the environmental impact by excluding hazardous substances from its manufacturing process.
