ON Semiconductor CPH5902G-TL-E Product Overview

The CPH5902G-TL-E from ON Semiconductor is a high-performance, P-Channel Trench MOSFET designed to deliver efficiency and power density in a compact package. This semiconductor device is engineered to cater to a wide range of applications, including power management tasks, load switching, and battery protection circuits in consumer electronics, automotive, and industrial systems.

Key Features

• Low On-Resistance: The device features an exceptionally low on-resistance, which minimizes conduction losses and improves overall efficiency.
• High-Speed Switching: Engineered for fast switching performance, the CPH5902G-TL-E can operate at high frequencies, which is ideal for efficient power conversion and regulation.
• Small Footprint: Housed in a compact SOT-23 package, it is suitable for space-constrained applications without sacrificing performance.
• Low Drive Voltage: It operates at low gate drive voltages, making it compatible with a variety of control circuits and reducing power consumption.
• High-Temperature Performance: With an operating temperature range of -55°C to +150°C, this MOSFET can withstand harsh environments and maintain stable performance.

Applications

• Power Management Systems
• DC/DC Converters
• Battery Powered Devices
• Load Switching Circuits
• Automotive Electronics
• Portable Electronic Devices

Technical Specifications

The CPH5902G-TL-E boasts a drain-source voltage (Vdss) of -20V, a continuous drain current (Id) of -3A, and a power dissipation (Pd) of 1.25W. The RDS(on) value is typically 70 mΩ at VGS = -4.5V, indicating a highly efficient current flow through the device when it's in the 'on' state.

Quality and Reliability

ON Semiconductor is committed to delivering high-quality products. The CPH5902G-TL-E is manufactured to meet stringent quality standards, ensuring reliability and performance consistency for the end user. Whether for consumer, automotive, or industrial applications, this MOSFET is an excellent choice for designers looking for a robust and efficient power switching solution.
