Product Overview: FGH40T120SMD - ON Semiconductor

The FGH40T120SMD is a high-performance, Field Stop IGBT (Insulated Gate Bipolar Transistor) designed and manufactured by ON Semiconductor, a leader in energy-efficient innovations. This IGBT is specifically engineered to offer an optimal balance between switching performance and conduction losses, making it an excellent choice for a wide range of power applications.

Key Features

• High Current Rating: The device can handle a continuous collector current of up to 40A, making it suitable for high-power applications.
• High Voltage Capability: With a collector-emitter voltage rating of 1200V, the FGH40T120SMD is designed for circuits that require high voltage operation.
• Low V<sub>CE(sat): The device offers a low collector-emitter saturation voltage, which enhances efficiency by minimizing conduction losses.
• Fast Switching Speed: The IGBT provides fast switching characteristics, contributing to reduced switching losses and improved system performance.
• Co-Packaged Free Wheeling Diode: A fast and soft recovery diode is co-packaged with the IGBT, which is essential for efficient switching and protection against reverse voltage spikes.

Applications

The FGH40T120SMD is suitable for a variety of applications that require efficient power conversion and control, including:

• Uninterruptible Power Supplies (UPS)
• Motor Drives
• Power Inverters
• Induction Heating
• Switch Mode Power Supplies (SMPS)

Quality and Reliability

ON Semiconductor is committed to delivering high-quality products. The FGH40T120SMD is built to meet stringent quality standards, ensuring reliable performance in demanding environments. It is also RoHS compliant, reflecting ON Semiconductor's dedication to environmental responsibility.

Technical Specifications

Parameter Value Collector-Emitter Voltage (V<sub>CE) 1200V Collector Current (I<sub>C) 40A Collector-Emitter Saturation Voltage (V<sub>CE(sat)) Typically low Switching Speed Fast Operating Temperature Specified over a wide range

With its robust design and advanced technology, the FGH40T120SMD from ON Semiconductor stands out as a powerful and efficient solution for designers looking to optimize their power management systems.
