ON Semiconductor LM337TG Adjustable Negative Voltage Regulator

The LM337TG from ON Semiconductor is a versatile and reliable adjustable negative voltage regulator designed to offer a convenient and robust solution for applications requiring a regulated output voltage. This device is capable of supplying in excess of 1.5 A over an output voltage range of -1.2 V to -37 V, making it an excellent choice for diverse electronic circuits. The LM337TG is housed in a TO-220 package, ensuring easy integration into a wide range of electronic devices.

Key Features

• Output Voltage Range: The LM337TG provides an adjustable output voltage from -1.2 V to -37 V, allowing for flexibility in various circuit designs.
• Output Current: Capable of delivering 1.5 A of output current, this regulator can handle a significant load, making it suitable for multiple applications.
• Thermal Overload Protection: The device includes safety features such as thermal overload protection, which helps prevent damage from overheating.
• Short Circuit Protection: Short circuit protection is built into the LM337TG, ensuring the regulator and your circuit remain safe in the event of a fault.
• Output Transistor Safe-Area Compensation: With built-in safe-area compensation for the output transistor, the device offers stable performance under varying conditions.

Applications

The LM337TG is ideal for a variety of applications where a stable and adjustable negative voltage is required. Common uses include power supplies, instrumentation, and operational amplifier systems, among others. Its ability to handle a substantial load current also makes it suitable for high-power applications.

Quality and Reliability

ON Semiconductor is known for its commitment to quality, and the LM337TG is no exception. It is designed to meet the stringent requirements of the most demanding electronic systems, ensuring long-term reliability and performance. Whether you're designing a new system or upgrading an existing one, the LM337TG adjustable negative voltage regulator is a dependable choice that combines flexibility with robustness.
