ON Semiconductor M74VHC1GT126DF1G Single Non-Inverting Buffer

The M74VHC1GT126DF1G from ON Semiconductor is a high-speed CMOS single non-inverting buffer fabricated with silicon gate CMOS technology. Designed to meet the demands of high-performance digital systems, this buffer is a key component for applications requiring a single buffer line driver with a 3-state output. The 3-state output stage is controlled by a separate enable input (OE), allowing the user to put the output into a high impedance state, which is essential for multiplexing and bus-oriented applications.

This device is capable of transforming slowly changing input signals into rapidly changing outputs, which is particularly important for applications that require fast edge rates in the presence of slow input transitions. The input is capable of interfacing to 3.3V or 5V signal levels, and the output can drive loads which are referenced to ground, making this buffer highly versatile for interfacing between different voltage domains in a system.

The M74VHC1GT126DF1G features a low power dissipation with a typical ICC of 2 µA, which is excellent for power-sensitive applications. It also has a high noise immunity characteristic of CMOS devices, ensuring reliable operation even in noisy environments. The device has a wide operating voltage range from 2V to 5.5V, making it suitable for a variety of digital applications.

ON Semiconductor has packaged this buffer in an ultra-small, leadless 5-pin SC-70 (SOT-353) package, which saves valuable board space in compact electronic assemblies. The leadless design also contributes to improved thermal performance and reduced parasitics. This product is guaranteed to meet the requirements of JEDEC standard no. 7A at 3.3V ± 0.3V, 5V ± 0.5V.

With its robust design and high-speed performance, the M74VHC1GT126DF1G is an excellent choice for a wide range of applications, including bus driving, memory address driving, and clock driving circuits. Its reliability and ON Semiconductor's commitment to quality make it a smart choice for designers who require a high-performance non-inverting buffer in their digital systems.

For detailed specifications, application circuits, and additional information, designers should refer to the official datasheet and product documentation available from ON Semiconductor's website or authorized distributors.
