MBRS4201T3G - ON Semiconductor Schottky Barrier Rectifier

The MBRS4201T3G is a robust Schottky barrier rectifier designed and manufactured by ON Semiconductor, a leading provider of semiconductor-based solutions. This component is engineered for high-efficiency power management tasks and is particularly suitable for applications that require low voltage drop and energy-saving characteristics.

Key Features

• Voltage and Current Ratings: The device has a maximum repetitive peak reverse voltage of 200V and a forward continuous current rating of 4A, making it suitable for a wide range of applications.
• Low Forward Voltage Drop: With a low forward voltage drop, the MBRS4201T3G ensures minimal power loss during operation, which enhances overall system efficiency.
• High Surge Capability: The rectifier can withstand high surge currents, providing reliable performance under transient conditions and enhancing the durability of the end application.
• Thermal Performance: The MBRS4201T3G has an excellent thermal performance due to its low thermal resistance, allowing for stable operation over a wide temperature range.
• Surface Mount Package: Housed in an SMB (DO-214AA) package, the device is optimized for automated assembly processes and is suitable for space-constrained applications.
• Environmentally Friendly: This rectifier is lead-free and RoHS compliant, making it an environmentally friendly choice for electronic designs.

Applications

The MBRS4201T3G is versatile and can be used in various applications, including:

• Switching power supplies
• Converters
• Free-wheeling diodes
• Reverse battery protection
• DC-DC modules
• Automotive applications

With its robust design and high reliability, the MBRS4201T3G from ON Semiconductor is an excellent choice for engineers and designers looking to improve the efficiency and longevity of their power management systems. Its combination of low power loss, high surge capability, and compact form factor makes it a valuable component in any power conversion or management circuit.
