ON Semiconductor MC14093BDTR2G Product Overview

The MC14093BDTR2G is a versatile quad 2-input NAND Schmitt Trigger from ON Semiconductor, designed to operate with particularly high efficiency in integrated circuit applications. This device is a fundamental component for a wide range of digital and signal processing tasks in electronic systems. Its robust design and reliable performance make it suitable for various applications, including waveform shaping, noise filtering, and implementing logic functions.

Constructed with high−performance silicon−gate CMOS technology, the MC14093BDTR2G offers significant advantages such as low power consumption and high noise immunity. This technology ensures minimal power loss during operation, making it an eco-friendly choice for energy-conscious designs. Moreover, the device is characterized by a wide operating voltage range from 3V to 18V, which provides designers with the flexibility to use it in systems with different power requirements.

One of the key features of the MC14093BDTR2G is its Schmitt Trigger input, which enhances the noise immunity and transforms slowly changing input signals into sharply defined jitter-free output signals. This is essential for applications where signal stability is crucial. The quad configuration of the device means it contains four independent NAND Schmitt Triggers in a single package, enabling compact and efficient circuit designs.

Available in a TSSOP-14 package, the MC14093BDTR2G is designed for surface-mount technology (SMT), which allows for high-density mounting and is well-suited for automated assembly processes. The device's temperature range of -55°C to +125°C ensures reliable operation under extreme conditions, catering to industrial and automotive applications that require high levels of durability and performance.

With its combination of high functionality, low power consumption, and robustness, the MC14093BDTR2G from ON Semiconductor is an excellent choice for designers looking to implement reliable logic functions and signal processing features in their electronic projects.

Whether you're working on consumer electronics, automotive systems, or industrial controls, the MC14093BDTR2G provides the performance and quality expected from a leading semiconductor manufacturer.
