ON Semiconductor MC33072DR2G Operational Amplifier

The MC33072DR2G is a high-performance operational amplifier from ON Semiconductor, designed to offer a perfect blend of features for a wide range of applications. This operational amplifier, commonly referred to as an op-amp, is characterized by its high gain, wide bandwidth, and low input offset voltage. It is an ideal choice for analog signal processing tasks, such as filtering, amplification, and conditioning in industrial, automotive, and consumer electronic products.

Key Features

• High Gain Bandwidth Product: The MC33072DR2G boasts a gain bandwidth product of 4.5 MHz, which ensures ample bandwidth for a variety of audio and video applications.
• Low Input Offset Voltage: Precision is key in signal processing, and this op-amp has a low input offset voltage, which minimizes error and enhances accuracy in sensitive applications.
• Wide Supply Voltage Range: With a supply voltage range from 3 V to 44 V, the MC33072DR2G is versatile and can be used in multiple configurations and with various power supplies.
• Large Output Voltage Swing: The op-amp can swing outputs close to the supply rails, which maximizes the dynamic range in applications such as audio amplification.
• Low Total Harmonic Distortion: It ensures high fidelity in audio applications by keeping the total harmonic distortion (THD) low.
• Single or Dual Supply Operation: This feature provides design flexibility, allowing the MC33072DR2G to be used in systems that have either a single or a dual supply voltage.

Applications

The MC33072DR2G is suitable for a wide range of applications, including:

• Audio and video equipment
• Signal generators and filters
• Data acquisition systems
• Industrial control systems
• Automotive electronics
• Medical instrumentation

Package and Quality

The operational amplifier is available in an 8-pin SOIC package, which is compact and suitable for surface-mount technology (SMT). ON Semiconductor's commitment to quality ensures that the MC33072DR2G meets stringent industry standards for performance and reliability, making it a reliable choice for both commercial and industrial applications.

With its robust feature set and flexible operation, the MC33072DR2G from ON Semiconductor stands out as a high-quality component for precision electronic designs.
