Maxim Integrated MAX4952ACTI+ High-Speed Differential Signal Switch

The MAX4952ACTI+ is a high-performance, dual 2:1 multiplexer/demultiplexer designed by Maxim Integrated for differential signal switching. This device is particularly suited for applications requiring high-speed data transfer and signal integrity, such as PCI Express (PCIe), Serial ATA (SATA), and other serial communication protocols.

With its capability to operate at data rates up to 8.0Gbps, the MAX4952ACTI+ ensures minimal signal distortion and attenuation, making it an ideal choice for high-speed signal routing. The integrated switch provides two differential channels, each with two inputs and one output, allowing flexible signal routing for various high-speed interfaces.

Key Features:

• High Data Rate: Supports data rates up to 8.0Gbps, which is essential for applications such as PCIe 2.0, SATA 3.0, and other high-speed communication standards.
• Low Crosstalk: Exhibits exceptionally low crosstalk between channels, minimizing interference and ensuring signal integrity.
• Low Bit-to-Bit Skew: Provides a low bit-to-bit skew, which is critical for maintaining the quality and timing of high-speed serial data streams.
• Wide Operating Temperature Range: The device operates over a broad temperature range from -40°C to +85°C, making it suitable for use in various environments.
• Pin Configuration: Available in a compact 38-pin TQFN package, the MAX4952ACTI+ is designed for space-constrained applications.
• Power Supply: Operates from a single 3.3V supply, simplifying power management in system design.

Applications:

• High-speed data communication links
• PCI Express (PCIe) switching
• Serial ATA (SATA) interface switching
• Server and storage subsystems
• Networking equipment
• Redundant signal paths for high-reliability systems

The MAX4952ACTI+ from Maxim Integrated is a versatile, high-speed switch that delivers performance and reliability for the most demanding data communication applications. Its advanced design and robust feature set make it a top choice for designers looking to optimize their high-speed differential signal routing.
