The ON Semiconductor MC33074ADTBR2 is a high-performance operational amplifier (op-amp) that delivers exceptional accuracy and stability. It is designed to meet the stringent requirements of a wide range of electronic applications, from industrial control systems to consumer electronics. This versatile op-amp features a quad-circuit configuration and comes in a TSSOP-14 package, making it suitable for compact designs where space is at a premium.

Key Features

• Wide Supply Voltage Range: The MC33074ADTBR2 operates on a supply voltage range from 3 V to 44 V, accommodating various application needs and ensuring compatibility with both single and dual supply operations.
• High Gain Bandwidth Product: With a gain bandwidth product of 4.5 MHz, this op-amp is capable of handling high-speed signals, making it ideal for audio processing, filtering, and other signal conditioning applications.
• Low Input Offset Voltage: The device boasts a low input offset voltage, which minimizes error and enhances overall system accuracy.
• Output Short-Circuit Protection: Built-in output short-circuit protection ensures that the device is safeguarded against potential damage from output to ground or supply shorts.
• Low Total Harmonic Distortion: The MC33074ADTBR2 is designed to produce low total harmonic distortion (THD), which is crucial for high-fidelity audio applications and precision instrumentation.

Applications

The MC33074ADTBR2 is a versatile component that can be used in a variety of applications. Its robust performance makes it suitable for:

• Audio processing equipment
• Active filters and signal conditioning
• Analog-to-digital converters
• Sensor interfaces
• Industrial control systems
• Professional audio equipment
• Automotive systems

Quality and Reliability

ON Semiconductor is known for its commitment to quality, and the MC33074ADTBR2 is no exception. It is manufactured using high-grade materials and subjected to rigorous testing to ensure it meets the highest standards of reliability and performance.
