ON Semiconductor MC74HC08ADR2G - Quad 2-Input AND Gate

The ON Semiconductor MC74HC08ADR2G is a high-performance, quad 2-input AND gate integrated circuit that utilizes silicon-gate CMOS technology. This device is designed to operate at a wide range of voltages, from 2V to 6V, while providing a low-power and high-speed solution for various digital logic applications. Its robust design ensures that it is compatible with TTL levels and can be used in systems that require a high degree of precision and reliability.

Key Features

• Logic Type: Quad 2-Input AND Gate
• Package / Case: SOIC-14
• Mounting Type: Surface Mount
• Operating Temperature: -55°C to +125°C
• Supply Voltage Range: 2V to 6V
• Logic Level - High: 1.5V to 3.5V (depending on Vcc)
• Logic Level - Low: 0.5V to 1.5V (depending on Vcc)
• Current - Quiescent (Max): 2µA
• Output Current - High, Low: 5.2mA, 5.2mA

Product Description

The MC74HC08ADR2G is a logic device that contains four independent gates, each of which performs the logic AND function. Its output is high only when both inputs are high, making it an essential component for creating complex logic circuits. The low power consumption and high noise immunity of CMOS technology, combined with the ability to drive 10 LSTTL loads, make this device versatile and suitable for a wide array of applications, including mobile devices, computers, data processing, and control systems.

This product is offered in a compact SOIC-14 package, allowing for efficient use of board space in surface-mounted technology (SMT) designs. The MC74HC08ADR2G is characterized for operation from -55°C to +125°C, ensuring reliable performance in extreme temperature environments.

ON Semiconductor's commitment to quality and environmental sustainability is reflected in the MC74HC08ADR2G's compliance with RoHS and Green Product standards, making it a responsible choice for designers looking to reduce the environmental impact of their electronic products.
