Same model may have multiple batches, images only for reference.

MC74HC1G32DTT1G

Name: MC74HC1G32DTT1G
Brand: ON Semiconductor
SKU: 223804
Availability: InStock
Rating: 5 (32 reviews)

Part No	MC74HC1G32DTT1G
Manufacturer	ON Semiconductor
Catalog	Logic - Gates and Inverters
Description	IC GATE OR 1CH 2-INP 5-TSOP
Datasheet	MC74HC1G32DTT1G Datasheet
Sample
ECAD Module

	New List Existing List This product has been added to your List. List Name:

Shipping Information

Shipped from	HK warehouse
Expected Shipping Date	Ship today if order in (HKT)
Supplier Lead-Time	Call for availability
Estimate shipping fee	Enter your destination to get a shipping estimate Estimate Shipping Fee

Pricing & Ordering $0.138

Quantity

Unit Price

Ext. Price

305+

$0.1640

$50.020

745+

$0.1350

$100.575

1,150+

$0.1310

$150.650

1,575+

$0.1270

$200.025

2,050+

$0.1220

$250.100

2,730+

$0.1100

$300.300

* The above prices does not include taxes and freight rates, which will be calculated on the order pages.

Availability: 95,100 pieces

MOQ: 305 pcs

Order Increment : 1 pcs

Qty:

*Need More Quantity? *Request a Bulk Quantity Quotation?

Products specifications

Categories	Integrated Circuits
Manufacturer	ON Semiconductor
Packaging	Reel - TR
Status	Active
Logic Type	OR Gate
Number of Circuits	1
Number of Inputs	2
Supply Voltage - Operating	2 V to 6 V
Current - Quiescent (Max)	1μA
Current - Output High, Low	2.6mA, 2.6mA
Logic Level - Low	0.5 V to 1.8 V
Logic Level - High	1.5 V to 4.2 V
Max Propagation Delay @ V, Max CL	17ns @ 6V, 50pF
Temperature Range - Operating	-55°C to 125°C
Mounting	SMD (SMT)
Case / Package	5-TSOP
Dimension	SOT-23-5 Thin, TSOT-23-5
Win Source Part Number	022763-MC74HC1G32DTT1G
Popularity	Medium
Fake Threat In the Open Market	59 pct.
Supply and Demand Status	Limited

Description

ON Semiconductor MC74HC1G32DTT1G Single 2-Input OR Gate

The ON Semiconductor MC74HC1G32DTT1G is a high-performance CMOS single 2-input OR gate that offers a compact and efficient solution for a wide range of digital logic applications. This advanced technology device has been designed to operate with a supply voltage range from 2V to 6V, making it suitable for battery-operated and low-voltage systems while providing the ability to interface with standard 5V logic signals.

Featuring a small surface-mount package, the MC74HC1G32DTT1G is ideal for space-constrained applications. Its SOT-416 (SC-70) package ensures a minimal footprint on the PCB, allowing for high-density circuit designs. Despite its small size, this OR gate delivers high noise immunity and low power consumption, characteristics that are essential for modern electronic devices.

The device is capable of driving up to 10 LSTTL loads, which means it can easily interface with older logic families, providing a bridge between legacy systems and newer digital components. The MC74HC1G32DTT1G is characterized for operation from -55°C to +125°C, ensuring reliable performance across a broad range of environmental conditions.

With fast propagation delay times and balanced rise and fall times, the MC74HC1G32DTT1G is optimized for high-speed operation without sacrificing power efficiency. This makes it an excellent choice for use in telecommunications, computing, and consumer electronics where speed and power considerations are paramount.

For designers and engineers looking for a dependable logic solution, the ON Semiconductor MC74HC1G32DTT1G offers a mix of high-speed performance, low power consumption, and small package size. Its compatibility with a wide operating voltage range and the ability to interface with various logic levels make it a versatile component for any digital logic design.

Whether you are designing a complex digital system or simply need a reliable OR gate for a basic logic function, the MC74HC1G32DTT1G from ON Semiconductor is a solid choice that promises to deliver both performance and quality.
