The MC74VHC1G04DFT1G is a high-speed CMOS inverter fabricated with silicon gate CMOS technology. Designed by ON Semiconductor, it achieves the high-speed operation similar to equivalent Bipolar Schottky TTL while maintaining the CMOS low power dissipation. This product is a testament to ON Semiconductor's commitment to providing energy-efficient and high-performance components for a wide range of electronic applications.

Key Features

• High Speed: The device boasts a propagation delay time of approximately 5.2 ns at a 5V supply voltage, which is ideal for high-speed applications.
• Low Power Dissipation: It has a low power consumption with a static current of only 1 µA maximum, making it suitable for battery-operated devices.
• High Noise Immunity: With a V_NN/V_CC noise immunity of 28%, the inverter offers robust performance even in electrically noisy environments.
• Power Down Protection: Inputs and outputs are protected against −0.5V to V_CC + 0.5V, ensuring the device is safeguarded during power-down situations.
• Wide Operating Voltage Range: The operating voltage range is from 2V to 5.5V, accommodating various logic level requirements.
• Lead-Free and RoHS Compliant: The device is lead-free and RoHS compliant, making it an environmentally friendly choice for electronic manufacturers.
• Compact Packaging: It comes in a small SC-70-5/SOT-353 package, which is perfect for space-constrained applications.

Applications

The MC74VHC1G04DFT1G is versatile and can be used in a multitude of applications that require logic level conversion, wave shaping, or signal inversion, such as:

• Portable and battery-powered electronics
• Logic level translation for mixed-voltage systems
• Line drivers
• Oscillator circuits
• Waveform generation

ON Semiconductor's MC74VHC1G04DFT1G inverter combines efficiency with high performance, making it an excellent choice for designers looking to optimize their electronic circuits without compromising on speed or power consumption.
