Product Overview: MC74VHC1G132DFT2

The MC74VHC1G132DFT2 is a high-performance, single 2-input NAND Schmitt Trigger gate designed by ON Semiconductor. It is a part of the VHC family of products, which are known for their low power consumption and high noise immunity. This particular component is designed to operate with a 2V to 5.5V supply voltage range, making it suitable for a wide array of applications, including portable devices where power efficiency is crucial.

Key Features

• Advanced High-Speed CMOS Technology: The MC74VHC1G132DFT2 is built using advanced CMOS technology, which ensures high speed while maintaining low power dissipation.
• Power Down Protection: Equipped with power down protection on inputs and outputs, this component ensures that no excessive current is drawn if the input voltage exceeds the supply voltage.
• Low Power Consumption: With a low quiescent current, the device is an excellent choice for battery-operated equipment.
• High Noise Immunity: Characterized by a VHC logic level, the device boasts high noise immunity, which is essential for stable performance in electrically noisy environments.
• Wide Operating Voltage Range: The device can function over a broad voltage range from 2V to 5.5V, providing flexibility in various applications and compatibility with TTL levels.
• Lead-Free and RoHS Compliant: The MC74VHC1G132DFT2 adheres to environmental regulations with its lead-free and RoHS compliant design.

Applications

The MC74VHC1G132DFT2 is versatile and can be used in numerous applications. Its features make it ideal for:

• Wave and pulse shapers
• High-speed logic circuits
• Communication systems
• Portable and battery-powered electronics
• Embedded systems
• Signal processing

Package Information

The device is available in a space-saving SC-88A (SOT-353) surface-mount package, which is suitable for automated assembly processes and applications where board space is at a premium.

Quality and Reliability

ON Semiconductor is committed to providing high-quality products. The MC74VHC1G132DFT2 is subject to rigorous testing and quality control measures to ensure reliable performance in the field.
