Product Overview: MC74VHC1G32DFT1G

The MC74VHC1G32DFT1G is a high-performance, single-gate CMOS logic OR gate from ON Semiconductor, renowned for its low power consumption and high speed operation. This advanced logic gate is designed to operate with a power supply range of 2V to 5.5V, making it a versatile component for a wide array of applications in modern electronics. The device is tailored to meet the requirements of both 3.3V and 5V systems, allowing for seamless integration into mixed-voltage environments.

Constructed with silicon gate CMOS technology, the MC74VHC1G32DFT1G offers a propagation delay that is significantly lower than that of standard CMOS integrated circuits when operating at 5V. This makes it an ideal choice for high-speed applications where response time is critical. Additionally, the input structure provides protection against static discharge, ensuring reliability and longevity of the component in various operating conditions.

The device features a 2-input OR gate configuration, which can be used in a variety of logic circuits and digital systems. Its small footprint is encapsulated in a TSSOP-5 package, which is optimized for reduced space on printed circuit boards, making it perfect for compact and high-density electronic designs.

Key specifications of the MC74VHC1G32DFT1G include:

• Logic Type: OR Gate
• Logic Level: CMOS
• Number of Circuits: 1
• Number of Inputs: 2
• Output Current: 8 mA
• Supply Voltage (Vcc): 2V to 5.5V
• Propagation Delay Time: 3.9ns at 5V
• Operating Temperature Range: -55°C to +125°C
• Mounting Type: Surface Mount
• Package / Case: TSSOP-5

With its robust design and ON Semiconductor's commitment to quality, the MC74VHC1G32DFT1G is a reliable and efficient solution for designers looking to implement logic functions with minimal power draw and high noise immunity. Whether used in consumer electronics, automotive systems, or industrial controls, this OR gate offers a high-performance logic solution that combines speed and flexibility in a compact, surface-mount package.
