ON Semiconductor MMBT4401LT1G NPN Bipolar Transistor

The MMBT4401LT1G is a high-performance NPN bipolar junction transistor (BJT) from ON Semiconductor, a leading manufacturer in the semiconductor industry. This versatile transistor is designed for general-purpose amplifier and switching applications, making it an essential component for a wide array of electronic circuits. Its compact SOT-23 package allows for efficient use of PCB real estate, making it suitable for space-constrained applications.

Key Features:

• Transistor Type: NPN - This type of transistor is well-suited for amplification due to its high current gain.
• Current Rating: The MMBT4401LT1G can handle continuous collector currents up to 600 mA, providing ample current for a variety of applications.
• Voltage Ratings: It offers a collector-emitter voltage (Vceo) of 40V, a collector-base voltage (Vcbo) of 60V, and an emitter-base voltage (Vebo) of 6V, ensuring stable operation under a range of conditions.
• Power Dissipation: With a power dissipation of 350 mW, this transistor can handle moderate power levels, making it suitable for a variety of electronic applications.
• Gain Bandwidth Product (fT): The device has a transition frequency of 300 MHz which is indicative of its capability to handle high-frequency signals.
• Operating Temperature Range: It can operate over a temperature range of -55°C to +150°C, providing reliability in diverse environmental conditions.
• Package: The SOT-23 package is widely used and recognized for its small footprint and ease of integration into surface-mount technology (SMT) processes.

Applications:

The MMBT4401LT1G transistor is ideal for a variety of applications where general-purpose switching and amplification are required. Common uses include:

• Signal amplification in audio and video equipment
• Driver stages in amplifiers
• Switching circuits in consumer electronics
• Control circuits in embedded systems
• Power management in portable devices

ON Semiconductor's commitment to quality ensures that the MMBT4401LT1G transistor is a reliable and efficient choice for designers and engineers seeking performance and durability. Whether for prototyping or mass production, this BJT is a go-to component for electronic projects requiring a dependable NPN transistor.
