The MMUN2214LT1G from ON Semiconductor is a high-performance bipolar transistor designed for use in a wide range of electronic applications. This versatile transistor is a part of ON Semiconductor's innovative product line, offering the reliability and efficiency that the brand is known for. With its compact SOT-23 package, the MMUN2214LT1G is ideal for space-constrained applications where small size and low power consumption are critical.

Key Features

• Transistor Type: PNP - Pre-Biased
• Configuration: Single
• Collector- Base Voltage (VCBO): 50V
• Collector-Emitter Voltage (VCEO): 50V
• Emitter-Base Voltage (VEBO): 5V
• Collector Current - Continuous (IC): 100mA
• DC Current Gain (hFE): 80 at 10mA, 5V
• Power - Max: 225mW
• Frequency - Transition: 50MHz
• Operating Temperature: -55°C to +150°C
• Mounting Type: Surface Mount
• Package / Case: TO-236-3, SC-59, SOT-23-3

Applications

The MMUN2214LT1G transistor is commonly used in signal processing, power management, and control systems. It is suitable for a variety of applications, including:

• Switching and Amplification
• Linear Amplification
• Power Regulation Circuits
• Interface Circuits
• Driver Stages in Hi-Fi Amplifiers and Television Circuits

Quality and Reliability

ON Semiconductor is committed to delivering high-quality components that meet the rigorous demands of the electronics industry. The MMUN2214LT1G transistor is no exception, providing consistent performance and a long operational lifespan. It is manufactured using ON Semiconductor's advanced process technology, ensuring that each unit meets the company's high standards for quality and reliability.

Environmental Compliance

The MMUN2214LT1G is compliant with RoHS and Green standards, reflecting ON Semiconductor's dedication to environmental sustainability. This commitment ensures that the product is not only effective but also environmentally friendly, minimizing the ecological impact of electronic components.
