ON Semiconductor NB7N017MMNG Clock Buffer

The ON Semiconductor NB7N017MMNG is a high-performance, low-skew 1:2 differential-to-3.3V LVPECL fanout buffer designed to distribute high-speed clocks in telecommunications, computing, and networking applications. This device is part of ON Semiconductor's extensive range of clock generation and distribution products, known for their reliability and precision.

Key Features

• High-Speed Operation: The NB7N017MMNG is capable of handling clock frequencies up to 3GHz, making it suitable for high-frequency applications.
• Low Skew: With an incredibly low output-to-output skew of 20ps, this buffer ensures synchronous signal distribution, which is critical for maintaining system timing integrity.
• Differential LVPECL Outputs: The device provides two low-voltage positive emitter-coupled logic (LVPECL) outputs from a single differential input, allowing for efficient signal distribution.
• Wide Voltage Range: It operates over a wide voltage range of 2.375V to 3.465V, offering flexibility in various power supply environments.
• Functional Integration: The NB7N017MMNG integrates an input equalization circuit that allows the device to recover degraded input signals, thus ensuring better signal integrity over longer distances or lower quality media.
• Power Supply Noise Rejection: The device features superior power supply noise rejection, contributing to stable operation in noisy electrical environments.

Applications

The NB7N017MMNG is ideal for applications requiring the distribution of a high-speed differential clock signal. It is particularly well-suited for use in:

• Networking equipment such as routers, switches, and base stations
• High-performance computing and data centers
• Telecommunications infrastructure
• Test and measurement systems
• Storage area networks

Product Specifications

Enclosed in a 16-pin QFN package, the NB7N017MMNG offers a compact solution for systems where space is at a premium. It operates over the industrial temperature range of -40°C to +85°C, ensuring reliability in a wide range of environmental conditions. The device also complies with RoHS and Pb-Free requirements, adhering to environmental standards for electronic components.

With its high-speed capabilities, low skew, and robust performance, the ON Semiconductor NB7N017MMNG clock buffer is an excellent choice for engineers looking to optimize their high-speed signal distribution with precision and reliability.
