Product Overview: NCP694HSAN33T1G

The NCP694HSAN33T1G is a high-performance, fixed output linear voltage regulator manufactured by ON Semiconductor. This device is designed to provide a precise 3.3V output with an input voltage range from 2.7V to 6.0V, making it an ideal choice for a wide array of electronic applications. The NCP694HSAN33T1G is highly regarded for its stability and reliability, capable of delivering up to 150mA of continuous output current.

Featuring a low dropout voltage and low quiescent current, this regulator ensures efficient operation, which is particularly beneficial for battery-powered devices. Its dropout voltage is typically only 120mV at 150mA load, which means that it can maintain a stable output even when the input voltage is close to the output voltage. The low quiescent current of typically 80µA contributes to extended battery life in portable applications.

The NCP694HSAN33T1G provides built-in thermal shutdown and current limit features, which protect the device and the load from damage due to overheating and overcurrent conditions. These safety features make it a reliable choice for critical applications that require a stable and protected power supply.

This voltage regulator comes in a compact SOT-23-5 package, which is suitable for space-constrained applications. It is also characterized for performance over an industrial temperature range of -40°C to +85°C, ensuring operation in a variety of environmental conditions. The NCP694HSAN33T1G is RoHS compliant, adhering to environmental standards and regulations.

In summary, the NCP694HSAN33T1G from ON Semiconductor is a versatile, efficient, and robust voltage regulator that provides a steady 3.3V output. Its low dropout performance, combined with safety features and a small form factor, make it an excellent choice for designers looking to incorporate a reliable power solution into their electronic devices.
