NTMYS2D9N04CLTWG ON Semiconductor – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

NTMYS2D9N04CLTWG

Part No NTMYS2D9N04CLTWG
Manufacturer ON Semiconductor
Catalog Transistors – FETs, MOSFETs – Single
Description MOSFET N-CH 40V 27A/110A 4LFPAK
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 40 V
Current - Continuous Drain (Id) @ 25°C 27A (Ta), 110A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Rds On (Max) @ Id, Vgs 2.8mOhm @ 40A, 10V
Vgs(th) (Max) @ Id 2V @ 11µA
Gate Charge (Qg) (Max) @ Vgs 35 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 2100 pF @ 20 V
Power Dissipation (Max) 3.7W (Ta), 68W (Tc)
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Surface Mount
Supplier Device Package LFPAK4 (5x6)
Case / Package SOT-1023, 4-LFPAK
Package Tape & Reel
Supply and Demand Status Limited
Win Source Part Number 1508896-NTMYS2D9N04CLTWG
Ultra Librarian 3D Model Ultra Librarian NTMYS2D9N04CLTWG CAD Model
