PV14-12R-L

Part No PV14-12R-L
Manufacturer Panduit Corp
Catalog Terminals
Description CONN RING CIRC 14-16AWG #1/2
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Terminal Type Circular
Stud/Tab Size 1/2 Stud
Thickness 0.032" (0.81mm)
Width - Outer Edges 0.720" (18.29mm)
Length - Overall 1.420" (36.07mm)
Mounting Type Free Hanging (In-Line)
Termination Crimp
Wire Gauge 14-16 AWG
Insulation Insulated
Features Brazed Seam, Serrated Termination
Color Blue
Contact Material Copper
Contact Finish Tin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1534593-PV14-12R-L
Ultra Librarian 3D Model Ultra Librarian PV14-12R-L CAD Model
