3240024

Part No 3240024
Manufacturer Phoenix Contact
Catalog Terminals
Description CONN RING CIRC 14-16AWG M5 CRIMP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Terminal Type Circular
Stud/Tab Size M5 Stud
Thickness 0.031" (0.79mm)
Width - Outer Edges 0.374" (9.50mm)
Length - Overall 0.906" (23.00mm)
Mounting Type Free Hanging (In-Line)
Termination Crimp
Wire Gauge 14-16 AWG
Insulation Insulated
Color Blue
Contact Material Copper
Contact Finish Tin
Package Bulk
Supply and Demand Status Normal
Win Source Part Number 1635535-3240024
Ultra Librarian 3D Model Ultra Librarian 3240024 CAD Model
