LNK306PN Real Image LNK306PN real image
Same model may have multiple batches, images only for reference.
LNK306PN Real Image LNK306PN real image
LNK306PN Real Image LNK306PN real image
Same model may have multiple batches, images only for reference.

LNK306PN

Part No LNK306PN
Manufacturer Power Integrations
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC OFFLINE SWIT OCP 8DIP
Datasheet
LNK306PN Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Tube/Rail
Status Active
Output Isolation Non-Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Buck, Buck-Boost, Flyback
Duty Cycle 69%
Frequency - Switching 66kHz
Fault Protection Current Limiting, Open Loop, Over Temperature, Short Circuit
Control Operating Temperature -40°C to 150°C (TJ)
Case / Package DIP-8B
Mounting Through Hole
Win Source Part Number 091764-LNK306PN
Family Name LNK306
Introduction Date September 02, 2004
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2022
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian LNK306PN CAD Model

Description

The LNK306PN is a high-popularity electronic component manufactured by Power Integrations. Its Win Source Part Number is 091764 and it is an integrated circuit with a DIP-8B case/package.

  • Output Isolation: non-isolated
  • Breakdown Voltage: 700V
  • Duty Cycle: 69%
  • Frequency-Switching: 66kHz
  • Fault Protection Features: current limiting, open loop, over temperature and short circuit
  • Supply Voltage: not specified
  • Operating Temperature Range: -40°C to 150°C
  • Alternative Parts: VIPER17LN, VIPER17HN, and LNK306P
