The PE-0805CD391JTT is a ceramic chip inductor manufactured by Pulse Electronics. It's designed for use in a variety of high-frequency applications requiring small size and high performance. This inductor features a multilayer construction providing excellent electrical characteristics and reliability.

Applications

• RF Circuits
• Mobile Communication Devices
• Wireless LAN
• Bluetooth Modules
• Matching Networks
• Filters

Features

• Small Size (0805 package)
• High Self-Resonant Frequency (SRF)
• Excellent Q Factor
• Tight Inductance Tolerance
• Multilayer Construction
• RoHS Compliant

Benefits

• Miniaturization: The small 0805 package allows for use in compact electronic devices where space is limited.
• Improved RF Performance: The high SRF and Q factor contribute to efficient signal transmission and filtering in RF applications.
• Precise Inductance: The tight tolerance ensures consistent performance across different devices and applications.
• Reliable Operation: The multilayer construction provides excellent mechanical and electrical stability.
• Reduced Losses: High Q factor minimizes energy loss in the circuit.

Additional Details

The PE-0805CD391JTT has an inductance value of 390 nH (391). The “0805” designation refers to the physical dimensions of the component in inches (0.08 inch x 0.05 inch). The inductor is designed for automated surface mounting. The high self-resonant frequency allows it to be used in high frequency circuits without significant performance degradation. The Q factor, a measure of the inductor's efficiency, is typically high, reducing energy loss. The inductor's construction involves multiple layers of ceramic and conductive material, providing a robust and stable structure.

The inductor is designed to operate over a wide temperature range. Its small size and high performance make it ideal for use in mobile phones, wireless communication devices, and other applications where space is a premium. The PE-0805CD391JTT is a reliable and efficient component for high-frequency circuit design. The tight inductance tolerance is critical for applications where precise inductance values are required, such as in matching networks and filters. Its RoHS compliance makes it suitable for use in environmentally conscious applications.
