The SMB-1357-0-30CWLCSP-TR-05-0-13 is a power management integrated circuit (PMIC) from Qualcomm. This PMIC is specifically engineered for integration into mobile devices and portable electronics, delivering optimized power regulation and distribution for enhanced performance and efficiency.

Applications

• Mobile Phones
• Tablets
• Portable Gaming Devices
• GPS Navigation Systems
• Other Battery-Operated Gadgets

Features

• Integrated Power Solution: Consolidates multiple power management functions into a single IC.
• High Power Conversion Efficiency: Minimizes power loss and maximizes battery runtime.
• Ultra-Compact CWLCSP Package: Enables use in highly space-constrained environments.
• Multiple Configurable Outputs: Provides a range of regulated voltage outputs to support various system components.
• Comprehensive Protection Mechanisms: Protects against over-voltage, over-current, and thermal overloads.
• Low Standby Current: Reduces battery drain during idle or sleep modes.

Benefits

• Prolonged Battery Life: The PMIC's efficiency directly translates to longer operational periods between charges.
• Simplified Design and BOM: Reduces the number of external components needed, streamlining the design process and lowering overall costs.
• Smaller Footprint: The compact package allows for smaller and sleeker product designs.
• Increased System Reliability: Protection features enhance the robustness and longevity of the device.
• Minimized Power Waste: The PMIC's low quiescent current helps conserve energy when the device is not actively in use.

Technical Specifications

Detailed specifications can vary depending on the exact revision. However, typical parameters for Qualcomm SMB-1357 series PMICs generally include:

• Input Voltage Range: Typically between 2.8V and 5.5V.
• Output Voltage Rails: Multiple rails ranging from 0.8V to 3.3V, tailored to application needs.
• Switching Frequency: High frequency operation, often in the MHz range, to minimize external component size.
• Operating Temperature: Usually specified from -30°C to +85°C.
• Packaging: CWLCSP (Chip-Scale Package) for minimal board space.

Consult the official Qualcomm datasheet for SMB-1357-0-30CWLCSP-TR-05-0-13 for precise electrical characteristics, recommended application circuits, and detailed package information.
