NP36P06KDG-E1-AY Renesas Electronics America NP36P06KDG-E1-AY Real Image1 NP36P06KDG-E1-AY Real Image2 NP36P06KDG-E1-AY real image
Same model may have multiple batches, images only for reference.
NP36P06KDG-E1-AY Renesas Electronics America NP36P06KDG-E1-AY Real Image1 NP36P06KDG-E1-AY Real Image2 NP36P06KDG-E1-AY real image
NP36P06KDG-E1-AY Renesas Electronics America NP36P06KDG-E1-AY Real Image1 NP36P06KDG-E1-AY Real Image2 NP36P06KDG-E1-AY real image
Same model may have multiple batches, images only for reference.

NP36P06KDG-E1-AY

Part No NP36P06KDG-E1-AY
Manufacturer Renesas Electronics America
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET P-CH 60V 36A Automotive 3-Pin(2+Tab) D2PAK T/R / MOSFET P-CH 60V 36A TO-263
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Renesas Electronics America
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 36A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.5V @ 1mA
Max Gate Charge 54nC @ 10V
Max Input Capacitance 3100pF @ 10V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 1.8W (Ta), 56W (Tc)
Maximum Rds On at Id,Vgs 29.5 mOhm @ 18A, 10V
Temperature Range - Operating 175°C (TJ)
Mounting SMD (SMT)
Case / Package TO-263
Dimension TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number 1083328-NP36P06KDG-E1-AY
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name NP36P06KDG
Introduction Date May 07, 2007
ECCN EAR99
Country of Origin Japan
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian NP36P06KDG-E1-AY CAD Model

Description

The Renesas Electronics America NP36P06KDG-E1-AY is a P-Channel MOSFET from Renesas Electronics America, featuring a drain-source breakdown voltage of 60V and a continuous drain current of 36A (Tc) @ 25°C.

  • Channel Type: P-Channel
  • Drain-Source Breakdown Voltage: 60V
  • Continuous Drain Current: 36A (Tc) @ 25°C
  • Application: Discrete Semiconductor Products
  • Power Dissipation: 1.8W (Ta) and 56W (Tc)
  • Gate-Source Threshold Voltage: 2.5V @ 1mA
  • Maximum Gate Charge: 54nC @ 10V
  • Maximum Input Capacitance: 3100pF @ 10V
  • Package: TO-263
  • Temperature Range: 175°C (TJ)
  • Popularity: High
  • Supply and Demand Status: Limited
  • Alternatives: FQB47P06, FQB47P06TM, FQB47P06TM-AM002, and SPB80P06P E3045A
