RF201L2STE25 Rohm Semiconductor RF201L2STE25 Real Image RF201L2STE25 label picture
Same model may have multiple batches, images only for reference.
RF201L2STE25 Rohm Semiconductor RF201L2STE25 Real Image RF201L2STE25 label picture
RF201L2STE25 Rohm Semiconductor RF201L2STE25 Real Image RF201L2STE25 label picture
Same model may have multiple batches, images only for reference.

RF201L2STE25

Part No RF201L2STE25
Manufacturer Rohm Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 200V 2A PMDS
Datasheet
RF201L2STE25 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Rohm Semiconductor
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 200V
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Max) @ If 870mV @ 2A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 25ns
Current - Reverse Leakage @ Vr 10μA @ 200V
Mounting SMD (SMT)
Case / Package PMDS
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 182696-RF201L2STE25
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name RF201L2S
Introduction Date June 21, 2007
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2019
Ultra Librarian 3D Model Ultra Librarian RF201L2STE25 CAD Model

Description

The RF201L2STE25 is a standard diode manufactured by Rohm Semiconductor.

  • Type: Fast recovery diode
  • Maximum Reverse Voltage: 200V
  • Average Rectified Current: 2A
  • Forward Voltage: 870mV @ 2A
  • Reverse Recovery Time: 25ns
  • Current Leakage @ 200V: 10μA
  • Operating Temperature: Maximum of 150°C
  • Packaging: PMDS
  • Family: RF201L2S family
