RS1E220ATTB1

Name: RS1E220ATTB1
Brand: Rohm Semiconductor
SKU: 1089003
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

Part No	RS1E220ATTB1
Manufacturer	Rohm Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 30V 22A/76A 8HSOP / P-Channel 30 V 22A (Ta), 76A (Tc) 3W (Ta) Surface Mount 8-HSOP
Datasheet	RS1E220ATTB1 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Single
Mfr	Rohm Semiconductor
Package	Tape & Reel
FET Type	P-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	30 V
Current - Continuous Drain (Id) @ 25°C	22A (Ta), 76A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Rds On (Max) @ Id, Vgs	4.1mOhm @ 22A, 10V
Vgs(th) (Max) @ Id	2.5V @ 2mA
Gate Charge (Qg) (Max) @ Vgs	130 nC @ 10 V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	5850 pF @ 15 V
Power Dissipation (Max)	3W (Ta)
Temperature Range - Operating	150°C (TJ)
Mounting	SMD (SMT)
Supplier Device Package	8-HSOP
Package / Case	8-PowerTDFN
Base Product Number	RS1E
MSL Level	1 (Unlimited)
REACH Status	REACH Affected
ECCN	EAR99
HTSUS	8541.29.0095
Other Names	RS1E220ATTB1TR,RS1E220ATTB1DKR,RS1E220ATTB1CT
Standard Package	2,500
Win Source Part Number	1089003-RS1E220ATTB1
Ultra Librarian 3D Model	Ultra Librarian RS1E220ATTB1 CAD Model

Alternative Products

Description

The Rohm Semiconductor RS1E220ATTB1 is a P-channel MOSFET transistor with a maximum drain to source voltage of 30V and a continuous drain current of 22A (Ta) and 76A (Tc) @ 25°C.

Maximum On-State Resistance: 4.1mOhm @ 22A and 10V
Gate Charge: 130 nC @ 10 V
Package: 8-PowerTDFN package
Gate-Source Threshold Voltage: 2.5V @ 2mA
