The US1GL is a surface-mount rectifier diode manufactured by Rugao Dachang Electronics Co., Ltd. It is designed for general-purpose rectification in a variety of electronic circuits. This diode features a high surge current capability and a low forward voltage drop, contributing to efficient power conversion.

Applications

• Power Supplies
• Freewheeling Diode in Inductive Circuits
• Polarity Protection
• General Rectification
• Adaptors

Features

• Surface Mount Package: SMA (DO-214AC)
• Reverse Voltage: 1000V
• Forward Current: 1.0A
• Low Forward Voltage Drop
• High Surge Current Capability

Benefits

• Efficient Rectification: Low forward voltage drop minimizes power loss.
• Reliable Operation: High surge current capability protects against transient voltage spikes.
• Compact Design: Surface-mount package saves board space.
• High Voltage Handling: 1000V reverse voltage for high-voltage applications.

Technical Specifications

The US1GL has a maximum repetitive peak reverse voltage (VRRM) of 1000V and a maximum average forward rectified current (IF(AV)) of 1.0A. The forward voltage drop (VF) is typically 1.0V at IF = 1.0A. It is available in a SMA (DO-214AC) surface-mount package. The operating temperature ranges from -55°C to +150°C.
