The SL-101-T-19 is a terminal strip manufactured by Samtec Inc., designed to provide reliable board-to-board connections. Part of the SL series, this component offers a dependable solution for various electronic applications where consistent connectivity is critical.

Applications

• Test and Measurement: Used in multimeters, oscilloscopes, and signal generators for reliable signal connections.
• Industrial Automation: Employed in Programmable Logic Controllers (PLCs) and other automation equipment.
• Medical Devices: Found in patient monitoring systems, diagnostic equipment, and other medical electronics.
• Aerospace: Used in aircraft control systems and avionics equipment.
• Telecommunications: Employed in networking equipment and communication devices.

Features

• Number of Rows: Single row configuration, optimizing board space.
• Number of Positions: 1 position, designed for single connection points.
• Pitch: Standard 0.100" (2.54 mm) pitch, ensuring compatibility with standard PCBs.
• Termination Style: Through-hole termination, providing a robust mechanical connection to the PCB.
• Insulator Material: High-temperature thermoplastic, offering excellent insulation properties and resistance to soldering heat.
• Contact Material: Typically made from phosphor bronze or beryllium copper, known for good conductivity and durability.
• Contact Plating: Gold or tin plating on the contact area, providing reliable electrical contact and corrosion resistance.
• Operating Temperature: Suitable for a wide range of operating temperatures.

Benefits

• Reliable Connection: Ensures a stable and dependable electrical connection, minimizing signal loss.
• Durable Construction: Manufactured with high-quality materials, ensuring long-term reliability.
• Easy Installation: Through-hole termination facilitates easy soldering and integration into existing designs.
• Versatile Application: Suitable for various applications requiring a single-point connection.
• Cost-Effective: Offers a practical and economical solution for board-to-board connections.

Additional Details

The SL-101-T-19 terminal strip is designed for ease of use and consistent performance. Its through-hole termination provides a strong mechanical connection to the PCB. The high-temperature thermoplastic insulator ensures it can withstand reflow soldering processes. The gold or tin-plated contacts provide reliable electrical performance in various environmental conditions. This terminal strip is ideal for applications requiring a single, dependable board-to-board connection point.
