The Samtec Inc. connector is a male pin header type connector with 12 positions and two rows.

• Type: male pin header
• Number of Positions: 12
• Number of Rows: 2
• Positions Loaded: all
• Mounting Style: through-hole
• Pitch: 0.100" (2.54mm)
• Mating Contact Finish: gold (10.0μin / 0.25μm)
• Post Finish: tin
• Insulation Material: Polybutylene Terephthalate (PBT)
• Flammability Rating: UL94 V-0
• Shrouded: unshrouded
• Row Spacing: 0.100" (2.54mm)
• Mating Contact Length: 0.230" (5.84mm)
• Post Contact Length: 0.100" (2.54mm)
• Overall Contact Length: 0.430" (10.92mm)
• Insulation Height: 0.100" (2.54mm)
• Application: board to board or cable
• Temperature Range: -55°C ~ 125°C
• Supply and Demand Status: limited
• Manufacturer Pack Quantity: 1
• MSL Level: 1 (Unlimited)
