FN3258-55-52 Real Image
Same model may have multiple batches, images only for reference.

FN3258-55-52

Part No FN3258-55-52
Manufacturer Schaffner EMC Inc.
Catalog Power Line Filter Modules
Description LINE FILTER 55A CHASSIS MOUNT / Three Phase (Delta) EMC/EMI Line Filter 55 A AC DC ~ 60Hz Single Stage Terminal Block
Datasheet
FN3258-55-52 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters - Power Line Filter Modules
Mfr Schaffner EMC Inc.
Series FN 3258
Package Tray
Product Status Obsolete
Filter Type Three Phase (Delta)
Configuration Single Stage
Voltage - Rated AC (Phase to Ground/Neutral) 277 V
Voltage - Rated AC (Phase to Phase) 480 V
Current 55 A
Frequency - Operating DC ~ 60Hz
Applications General Purpose
Approval Agency CSA, ENEC, UR
Temperature Range - Operating -25°C ~ 100°C
Mounting Type Chassis Mount
Termination Style Terminal Block
Standard Package 6
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.30.8000
California Prop 65 Warning Information
Win Source Part Number 1339848-FN3258-55-52
Ultra Librarian 3D Model Ultra Librarian FN3258-55-52 CAD Model

Description

The Schaffner EMC Inc. FN 3258 series power line filter module is a high-quality filter that is perfect for use in a variety of applications.

  • Filter Type: Three-Phase (Delta)
  • Current: 55A
  • Voltage Rated AC (Phase to Ground/Neutral): 277V
  • Voltage Rated AC (Phase to Phase): 480V
  • Frequency Range: DC to 60Hz
  • Temperature Range: -25°C to 100°C
  • Mounting Type: Chassis Mount
  • Package: Tray
  • Approvals: CSA, ENEC, and UR
