SR05.TCT

Name: SR05.TCT
Brand: Semtech Corporation
SKU: 339889
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SR05.TCT
Manufacturer	Semtech Corporation
Catalog	TVS - Diodes
Description	TVS DIODE 5VWM 20VC SOT143
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Circuit Protection
Manufacturer	Semtech Corporation
Packaging	Reel - TR
Status	Active
Type	Steering (Rail to Rail)
Unidirectional Channels	2
STAND-OFF Voltage (Vwm)	5V (Max)
Minimum Breakdown Voltage	6V
Max Clamping Voltage	20V
Peak Pulse Current(Ippm)	25A (8/20μs)
Power Dissipation - Pd	500W
Power Line Protection	Yes
Applications	General Purpose
Capacitance @ Frequency	6pF @ 1MHz
Temperature Range - Operating	-55°C to 125°C (TJ)
Mounting	SMD (SMT)
Case / Package	SOT-143-4
Win Source Part Number	030790-SR05.TCT
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Ultra Librarian 3D Model	Ultra Librarian SR05.TCT CAD Model

Description

The SR05.TCT is a steering (rail to rail) SMD circuit protection component from Semtech Corporation.

Capacitance: 6pF @ 1MHz
Applications: General Purpose
Stand-off Voltage (Vwm): 5V (Max)
Breakdown Voltage (Min): 6V
Clamping Voltage (Max): 20V
Peak Pulse Current (Ippm): 25A (8/20μs)
Power Dissipation (Pd): 500W
Operating Temperature Range: -55°C to 125°C (TJ)
