Same model may have multiple batches, images only for reference.
D2425 Real Image
Same model may have multiple batches, images only for reference.

D2425

Part No D2425
Manufacturer Sensata-Crydom
Catalog Solid State Relays
Description SSR RELAY SPST-NO 25A 24-280V / Solid State SPST-NO (1 Form A) Hockey Puck
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Solid State Relays
Mfr Sensata-Crydom
Series 1
Package Bulk
Product Status Active
Mounting Type Chassis Mount
Circuit SPST-NO (1 Form A)
Output Type AC, Zero Cross
Voltage - Input 3 ~ 32VDC
Voltage - Load 24 V ~ 280 V
Load Current 25 A
Termination Style Screw Terminal
Package / Case Hockey Puck
Standard Package 20 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.49.0080
California Prop 65 Warning Information
Win Source Part Number 847089-D2425
Ultra Librarian 3D Model Ultra Librarian D2425 CAD Model

Description

The 847089-D2425 is a solid-state relay from the 1 series by Sensata-Crydom. It is designed for medium-power applications and features a screw terminal termination style.

  • Series: 1
  • Termination Style: Screw Terminal
  • Voltage Input: 3 to 32VDC
  • Output Type: AC Zero Cross
  • Circuit: SPST-NO (1 Form A)
  • Load Current: Up to 25A
  • Voltage Load: 24V to 280V
  • Mounting Type: Chassis Mount
  • Package: Hockey Puck
  • Bulk Package: 20 pcs
  • California Prop 65: Compliant
