The STW8Q14C is a high-power LED manufactured by Seoul Semiconductor. It is designed for various lighting applications requiring high luminous flux, high efficacy, and long lifetime. This LED is part of Seoul Semiconductor’s WICOP (Wafer Level Integrated Chip on PCB) series, which offers improved thermal performance and reliability.

Applications

• Automotive lighting (headlights, taillights, daytime running lights)
• Outdoor lighting (streetlights, floodlights)
• Indoor lighting (downlights, spotlights)
• Industrial lighting
• Backlighting for LCD displays

Features

• High luminous flux
• High efficacy
• Long lifetime
• WICOP (Wafer Level Integrated Chip on PCB) technology
• Low thermal resistance
• Compact size
• RoHS compliant

Benefits

• Provides bright and efficient illumination for various lighting applications.
• Reduces energy consumption and lowers operating costs.
• Offers long-term reliability, minimizing maintenance requirements.
• Improved thermal performance allows for higher drive currents and increased light output.
• Compact size enables smaller and more streamlined lighting designs.

Technical Specifications

The STW8Q14C typically operates at a forward current of 350mA to 1000mA, depending on the specific application. The forward voltage is typically around 3V. The luminous flux varies depending on the drive current and color temperature. The color temperature options typically range from cool white (5000K-6500K) to warm white (2700K-3200K). The operating temperature range is typically -40°C to +85°C. The LED is available in a surface-mount package.

This high-power LED is suitable for demanding lighting applications requiring high performance and reliability.
