The ESD3Z5C is an ESD protection diode manufactured by Shanghai Leiditech Electronic Technology Co., Ltd. It is designed to protect sensitive electronic components from damage caused by electrostatic discharge (ESD). It falls under Leiditech's END-OF-LIFE product category.

Applications

• Protection of USB interfaces
• Protection of HDMI ports
• Protection of Ethernet ports
• Protection of audio lines
• Protection of power lines

Features

• Low clamping voltage
• Fast response time
• Small package size
• Low leakage current
• High surge capability

Benefits

• Prevents ESD damage to sensitive components
• Improves system reliability
• Reduces warranty costs
• Extends product lifespan
• Easy to integrate into existing designs

Additional Details

The ESD3Z5C is typically available in a small surface mount package, such as SOD-323. It offers a standoff voltage appropriate for 5V systems and a low clamping voltage to protect downstream components. It meets industry standard ESD protection requirements, including IEC 61000-4-2. It is a transient voltage suppression (TVS) diode. Its low capacitance makes it suitable for protecting high-speed data lines without signal degradation. It protects against contact discharge events.

Given its END-OF-LIFE status, it's recommended to check with Shanghai Leiditech or authorized distributors for potential replacement options for new designs. Several other manufacturers offer ESD protection diodes with similar characteristics.
