The SSM9435GM is a P-Channel enhancement mode MOSFET produced by Silicon Standard Corporation. It is designed for load switching, power management, and other general-purpose applications where efficient and reliable switching is required.

Applications:

• Load Switch
• Power Management in Portable Devices
• Battery Protection Circuits
• DC-DC Converters

Features:

• P-Channel MOSFET
• Low On-Resistance (RDS(on))
• Low Gate Threshold Voltage (VGS(th))
• High Density Cell Design for Ultra Low RDS(ON)
• Small Surface Mount Package

Benefits:

• Efficient load switching with minimal power loss
• Extended battery life in portable applications due to low RDS(on)
• Simple gate drive requirements
• Compact size suitable for miniaturized designs

Additional Details:

The SSM9435GM has a drain-source voltage (VDS) rating of -30V and a continuous drain current (ID) rating of -5.2A. The on-resistance (RDS(on)) is typically 45 mΩ at VGS = -10V and 70 mΩ at VGS = -4.5V. The device is available in a SOT-23 package. It is designed to offer a good balance between switching speed, on-resistance, and gate charge, making it suitable for various low-voltage applications.
