The SiTime SIT8002AC-33-33E-25 is a programmable oscillator belonging to the SiTime SiT8002 series. These oscillators are well-regarded for their high performance, compact form factor, and robust reliability. Based on the part number, 'AC' likely designates specific operating voltage and temperature range characteristics, '33' might refer to particular configuration settings or performance metrics, '33E' indicates a specific combination of supply voltage and stability parameters, and '25' suggests an output frequency of 25 MHz. This oscillator is engineered to deliver a stable and precise clock signal, making it suitable for various electronic applications.

Applications

• Consumer electronics
• Industrial automation
• Networking devices
• Embedded systems
• Microcontrollers

Features

• Frequency: 25 MHz
• Supply Voltage: 3.3V
• High frequency stability
• Compact size
• Low power consumption
• Wide operating temperature range
• Programmable for customizable applications

Benefits

• Delivers a highly accurate and stable clock signal, enhancing overall system performance.
• Enables compact designs due to its small footprint.
• Provides flexibility through programmability, allowing users to tailor the oscillator to specific requirements.
• Reduces power consumption, contributing to energy efficiency.
• Ensures reliable operation in harsh environments thanks to its wide temperature range.

The SiT8002 series oscillators leverage MEMS (Micro-Electro-Mechanical Systems) technology, which offers advantages over conventional quartz oscillators in terms of size, dependability, and robustness. This oscillator is typically used in applications where precise timing is crucial, such as data communication, signal processing, and embedded systems. Its low jitter and high stability ensure clean clock signals, minimizing errors and improving system accuracy.

Specifications:

• Frequency Stability: ±20 ppm to ±50 ppm (depending on the specific configuration)
• Operating Temperature Range: -40°C to +85°C
• Supply Voltage: 3.3V
• Output Signal: CMOS
• Package: Typically 2.5 x 2.0 mm or smaller
