Same model may have multiple batches, images only for reference.
GBU1508TB Real Image
Same model may have multiple batches, images only for reference.

GBU1508TB

Part No GBU1508TB
Manufacturer SMC Diode Solutions
Catalog Bridge Rectifiers
Description BRIDGE RECT 1PHASE 800V 15A GBU
Datasheet
GBU1508TB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer SMC Diode Solutions
Packaging AMMO PACKAGE
Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 800V
Current - Average Rectified (Io) 15A
Voltage - Forward (Vf) (Max) @ If 1.1V @ 15A
Current - Reverse Leakage @ Vr 5μA @ 800V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package GBU
Win Source Part Number 1040866-GBU1508TB
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian GBU1508TB CAD Model

Description

The SMC Diode Solutions GBU1508TB is a standard single-phase diode with a through-hole mounting and a maximum voltage peak reverse of 800V.

  • Mounting Type: Through-Hole
  • Maximum Voltage Peak Reverse: 800V
  • Current Average Rectified (Io): 15A
  • Voltage Forward (Vf) (Max) @ If: 1.1V @ 15A
  • Current Reverse Leakage @ Vr: 5μA @ 800V
  • Case: GBU
