Products specifications

Category Circuit Protection>TVS - Diodes
Mfr STMicroelectronics
Series BZW50, TRANSIL™
Package Tube
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 33V
Voltage - Breakdown (Min) 36.6V
Voltage - Clamping (Max) @ Ipp 76V
Current - Peak Pulse (10/1000µs) 789A (8/20µs)
Power - Peak Pulse 5000W (5kW)
Power Line Protection No
Applications General Purpose
Capacitance @ Frequency 5750pF @ 1MHz
Mounting Type Through Hole
Package / Case R-6, Axial
Supplier Device Package R-6
Base Product Number BZW50
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Other Names BZW50-33-ND,BZW5033,497-7221-5
Standard Package 100
Win Source Part Number 1200930-BZW50-33
Ultra Librarian 3D Model Ultra Librarian BZW50-33 CAD Model

Description

The BZW50-33 from STMicroelectronics is a high-performance Transil™ diode designed to provide reliable protection against voltage transients. This bidirectional surge suppressor is specifically engineered to protect sensitive electronic equipment against voltage spikes and surges that can occur due to lightning, load switch, or other transient events.

Key Features

  • Peak Pulse Power Dissipation: The BZW50-33 can handle up to 5000W (10/1000µs surge) of peak pulse power, ensuring robust protection for your circuits during transient conditions.
  • Stand-off Voltage: With a stand-off voltage of 33V, it is optimized for a wide range of applications that require a specific voltage threshold for protection.
  • Fast Response Time: The device reacts quickly to transient overvoltage events, safeguarding components before damage can occur.
  • Low Clamping Voltage: Once the transient voltage surpasses the triggering threshold, the BZW50-33 clamps the voltage to a safe level, minimizing the risk to downstream components.
  • High Surge Capability: The diode's high surge capability ensures that it can handle large surges without performance degradation.
  • Package: Available in a rugged axial package, it is designed for easy integration into a variety of circuit designs.

Applications

The BZW50-33 is ideal for use in a range of applications where transient voltage protection is critical. This includes:

  • Power supply units
  • Telecommunication systems
  • Industrial electronics
  • Lightning protection systems
  • Automotive applications

Reliability and Safety

STMicroelectronics ensures that the BZW50-33 meets rigorous standards for reliability and safety. The device complies with international standards, including IEC 61000-4-5, which governs the protection of electrical and electronic equipment against surges. With its exceptional performance and reliability, the BZW50-33 is an excellent choice for designers looking to enhance the durability and longevity of their systems.
