STMicroelectronics L5986TR Step-Down Switching Regulator

The L5986TR from STMicroelectronics is a high-performance step-down switching regulator designed for modern electronic applications requiring efficient power conversion and management. This compact and versatile component is capable of delivering up to 3A of continuous output current with an input voltage range extending from 4.5V to 38V, making it suitable for a wide array of applications, including but not limited to industrial control systems, consumer electronics, and automotive devices.

The L5986TR employs an advanced high-speed switching technology that allows for a reduced external component count while maintaining excellent thermal performance and efficiency. With a fixed switching frequency of 250kHz, this regulator can utilize smaller inductors and capacitors, leading to a more compact and cost-effective power supply design.

Featuring an internal fixed or adjustable output voltage, the L5986TR provides designers with flexibility in their circuit designs. The adjustable version can set the output voltage from 0.6V to the input voltage, ensuring compatibility with the latest low-voltage digital ICs. The fixed output version comes in several common voltages, catering to standard power rails.

Protection features are paramount in power management, and the L5986TR does not disappoint. It includes overcurrent protection, thermal shutdown, and a power good signal for output voltage monitoring, which enhances the safety and reliability of the end application. Furthermore, the device supports both pulse-skipping mode and fixed frequency PWM operation, which allows for high efficiency across the full load range.

This regulator is available in a compact VFQFPN 16 package, which is designed to minimize space on the PCB and optimize thermal dissipation. The L5986TR is fully RoHS compliant and designed to meet the rigorous standards of the automotive and industrial markets, ensuring robustness and longevity in challenging environments.

With its combination of versatility, efficiency, and protection features, the STMicroelectronics L5986TR is an excellent choice for designers looking to implement a reliable and high-performance power supply in their next project.
