LD56050DPU110R Voltage Regulator The LD56050DPU110R is a high-performance, low-dropout voltage regulator from STMicroelectronics, designed to deliver a stable and noise-free voltage supply for sensitive electronic circuits. With its wide input voltage range and low quiescent current, this regulator is ideal for battery-powered applications, as well as for high-efficiency post-regulation in systems with multiple supply voltages.

The LD56050DPU110R boasts an impressive dropout voltage of just 50 mV at a 500 mA load, ensuring efficient operation even when the input voltage is close to the output voltage. Its output voltage is fixed at 1.1V, providing a precise reference for digital circuits and helping to maintain stable operation even under varying load conditions.

Safety features are paramount in voltage regulators, and the LD56050DPU110R does not disappoint. It includes thermal shutdown and current limiting, protecting both the regulator and the attached components from damage due to overheating or excessive current draw. Moreover, the device's low-noise performance, with a high power supply rejection ratio (PSRR), makes it suitable for noise-sensitive applications such as RF systems and precision analog circuits.

The LD56050DPU110R comes in a compact DFN10 package, making it easy to integrate into space-constrained designs. Its small footprint, combined with the low number of external components required for operation, enables designers to create compact, reliable, and high-performance power supply solutions.

Whether you're designing for consumer electronics, automotive systems, or industrial applications, the LD56050DPU110R from STMicroelectronics provides the performance and reliability needed to ensure your designs meet the highest standards for power supply regulation.
