The ST72F324BJ4B6 is a versatile 8-bit microcontroller from STMicroelectronics, designed to offer a balanced combination of performance and power efficiency for a wide range of embedded applications. This microcontroller is based on the industry-proven STM7 core and is tailored to meet the rigorous demands of automotive, industrial, and consumer markets.

Key Features

• Core: High-performance 8-bit STM7 CPU core operating at a maximum frequency of 16 MHz.
• Memory: Equipped with 16 Kbytes of Flash program memory, which is both highly reliable and low power, along with 1 Kbytes of RAM for efficient data handling.
• Peripherals: Includes a rich set of peripherals such as multiple 16-bit timers, an 8-bit ADC (Analog to Digital Converter), and a synchronous serial communication interface (SPI).
• I/O Ports: Features 25 multifunctional bidirectional I/O ports, providing flexibility for various input and output configurations.
• Operating Voltage: Supports an operating voltage range from 3.0V to 5.5V, making it suitable for a variety of power supply scenarios.
• Temperature Range: Designed to operate within an industrial temperature range of -40°C to 85°C, ensuring reliability in harsh environments.
• Package: Available in a 44-pin LQFP package, which is ideal for space-constrained applications.

Applications

The ST72F324BJ4B6 microcontroller is well-suited for applications that require a robust and flexible control solution, such as:

• Automotive systems, including body control modules and engine management
• Industrial control systems, such as PLCs and motor controllers
• Consumer electronics, including home appliances and personal gadgets
• Embedded systems requiring precise timing and control, like HVAC units and smart sensors

Development Support

STMicroelectronics provides comprehensive development support for the ST72F324BJ4B6, including software libraries, development kits, and a suite of debugging and programming tools, ensuring a smooth development process from prototype to production.
