STB80NF10T4 - N-Channel 100V - 0.0095 Ohm - 80A - D2PAK STripFET™ II Power MOSFET

The STB80NF10T4 is a high-performance N-Channel Power MOSFET from STMicroelectronics, designed to deliver efficiency and reliability for a wide range of applications. This MOSFET is part of the STripFET™ II family, which is renowned for its low on-resistance and low gate charge, making it an ideal choice for high-frequency switching and power management tasks.

With a drain-source voltage (V<sub>DS) of 100V, the STB80NF10T4 is capable of handling high voltage operations while maintaining robustness and stability. Its low on-resistance of just 0.0095 Ohm minimizes conduction losses, which is crucial for improving the overall efficiency of the system it's integrated into. This feature, combined with a high current capability of 80A, makes the STB80NF10T4 suitable for demanding applications such as DC-DC converters, motor control circuits, and power management solutions.

The device is encapsulated in a D2PAK package, which not only ensures a compact footprint but also provides excellent thermal performance. The package is designed to handle high levels of heat dissipation, which is essential for maintaining performance and longevity when operating at high currents or in high-temperature environments.

Additionally, the STB80NF10T4 boasts a low gate charge (Q<sub>G), which enhances its switching performance. This characteristic is particularly important for applications that require fast switching frequencies, as it helps to reduce switching losses and improves the overall response time of the circuit.

STMicroelectronics has designed the STB80NF10T4 with a focus on reliability. It features an avalanche ruggedness that protects the device in adverse conditions, making it a reliable choice for industrial and automotive applications where durability is a prime concern.

In summary, the STB80NF10T4 from STMicroelectronics is a powerful and efficient N-Channel Power MOSFET that offers low on-resistance, high current capability, and excellent thermal performance, packaged in a space-saving D2PAK outline. Its robust design and fast switching capabilities make it a versatile component for a variety of high-performance power management applications.
