The STD30NF06T4 is a high-performance N-channel Power MOSFET produced by STMicroelectronics, a leader in semiconductor solutions. This device is designed to deliver the efficiency and speed required by modern power supply applications. Utilizing ST's advanced STripFET™ technology, the STD30NF06T4 offers low on-resistance and low gate charge, which translates into superior switching performance and improved overall efficiency.

Key Features

• Low Threshold Drive: The device can be driven at lower gate voltages, making it compatible with a wider range of drive circuits and ensuring ease of use in various applications.
• High Current Capability: With a continuous drain current of 30A, the STD30NF06T4 is capable of handling high current loads, making it suitable for demanding environments.
• Low On-Resistance: The on-resistance of this MOSFET is typically just 0.035 ohms, which helps in reducing power losses and improving efficiency in electronic circuits.
• 100% Avalanche Tested: Each unit is rigorously tested for avalanche performance, ensuring reliability and robustness in applications where the MOSFET might be subjected to high-energy pulses.

Applications

The STD30NF06T4 is versatile and can be used in a variety of applications, including:

• Power Supply Switches
• DC-DC Converters
• Motor Control Circuits
• Automotive and High-Efficiency Power Management Systems

Reliability and Performance

STMicroelectronics is committed to providing electronic components that meet the highest standards of reliability and performance. The STD30NF06T4 is no exception, offering excellent thermal performance thanks to its robust package design. This MOSFET is a testament to ST's dedication to innovation and quality in the field of power electronics.

Package and Availability

The STD30NF06T4 is available in a DPAK (TO-252) package, which is suitable for surface-mount technology (SMT) and compatible with a wide range of PCB designs. For more information, datasheets, and purchasing options, visit the STMicroelectronics website or contact an authorized distributor.
