Product Overview: STD35NF06T4 - STMicroelectronics

The STD35NF06T4 is a cutting-edge N-channel MOSFET brought to you by STMicroelectronics, a global semiconductor leader known for its innovative and high-performance components. This MOSFET is part of the STripFET™ IV series, which represents a leap forward in technology, offering low on-resistance and low gate charge. The device is designed to serve a broad range of applications, making it a versatile choice for designers and engineers.

Key Features

• Low Threshold Drive: The STD35NF06T4 operates at a low gate threshold voltage, which allows for easy drive and efficient operation at low voltages.
• High Switching Efficiency: With a low gate charge and low on-resistance, this MOSFET achieves high switching efficiency, which is crucial for power management applications.
• Advanced Technology: The device utilizes STMicroelectronics' STripFET™ IV technology, offering improved performance in terms of conduction and switching losses.
• Robust Thermal Performance: The STD35NF06T4 is designed to handle high current and power levels with a robust thermal performance, ensuring reliability even under strenuous conditions.

Applications

The versatility of the STD35NF06T4 allows it to be used in a wide array of applications, including:

• Power supply switches
• High-efficiency DC-DC converters
• Motor control circuits
• Automotive applications
• Load switch applications

Specifications

The STD35NF06T4 boasts impressive specifications that cater to demanding power and control applications:

• Voltage - Breakdown (V<sub>(BR)DSS): 60V
• Current - Continuous Drain (I<sub>D) @ 25°C: 35A
• R<sub>DS(on) Max @ Id, Vgs: 14 mOhm @ 17.5A, 10V
• Power - Max: 80W

With its superior performance and reliability, the STD35NF06T4 from STMicroelectronics is an excellent choice for power management solutions where efficiency and thermal performance are critical. It is available in a surface-mount DPAK package, which is suitable for compact designs and where space is at a premium.
